Elektriniį presą SUPERTECH Q35Y-20 parduodama aukcione

Serial no.: 23001

Year of manufacture: 2023


Working force: 90 t (≈882 kN)

Material tensile strength: ≤ 450 N/mm²

Cutting angle: 8°

Stroke: 80 mm

Strokes per minute (80 mm stroke): 10 cpm

Strokes per minute (20 mm stroke): 36 cpm

Max engagement distance: 35 mm




Shearing – flat bar:

Max thickness x length (single stroke): 20 x 330 mm

Alternative capacity: 10 x 480 mm




Shearing – round bar: Ø 50 mm

Shearing – square bar: 50 x 50 mm




Angle / profile cutting:

Angle at 90°: 140 x 140 x 12 mm

Angle at 45°: 50 x 50 x 5 mm

T-profile at 90°: 140 x 140 x 12 mm

T-profile at 45°: 70 x 70 x 10 mm

I-profile at 90°: 160 x 86 x 6 mm

U-profile at 90°: 160 x 60 x 6.5 mm




Punching unit:

Max punching thickness: 20 mm

Max punching diameter (at max thickness): Ø 30 mm




Motor power: 5.5 kW

Voltage: 380 V / 3 Ph / 50 Hz




Overall dimensions (L x W x H): 1830 x 800 x 1900 mm

Machine weight: approx. 2200 kg




Accessories included:

• Punching dies (round): Ø 12, 16, 18, 20, 25, 30, 40, 50 mm

• Punching dies (slot / waist): 12x25, 14x30, 15x40, 16x50, 14x60 mm

• Lock-nut group for large hole punching

• Shutter mould: 100 x 20 x 1.5 mm

• Notching unit with 90° blade and 90° die holder

• Electrically adjustable length stop for bars, profiles and flat strips (up to 1000 mm)


Serial no: 23001
Year of manufacture: 2023
Working force: 90 t (≈882 kN)
Material tensile strength: ≤ 450 N/mm²
Cutting angle: 8°
Stroke: 80 mm
Strokes per minute (80 mm stroke): 10 cpm
Strokes per minute (20 mm stroke): 36 cpm
Max engagement distance: 35 mm
Shearing – flat bar:
Max thickness x length (single stroke): 20 x 330 mm
Alternative capacity: 10 x 480 mm
Shearing – round bar: Ø 50 mm
Shearing – square bar: 50 x 50 mm
Angle / profile cutting:
Angle at 90°: 140 x 140 x 12 mm
Angle at 45°: 50 x 50 x 5 mm
T-profile at 90°: 140 x 140 x 12 mm
T-profile at 45°: 70 x 70 x 10 mm
I-profile at 90°: 160 x 86 x 6 mm
U-profile at 90°: 160 x 60 x 6.5 mm
Punching unit:
Max punching thickness: 20 mm
Max punching diameter (at max thickness): Ø 30 mm
Motor power: 5.5 kW
Voltage: 380 V / 3 Ph / 50 Hz
Overall dimensions (L x W x H): 1830 x 800 x 1900 mm
Machine weight: approx. 2200 kg
Accessories included:
Punching dies (round): Ø 12, 16, 18, 20, 25, 30, 40, 50 mm
Punching dies (slot / waist): 12x25, 14x30, 15x40, 16x50, 14x60 mm
Shutter mould: 100 x 20 x 1.5 mm
brand: SUPERTECH
Lock-nut group for large hole punching
Notching unit with 90° blade and 90° die holder
Electrically adjustable length stop for bars
profiles and flat strips (up to 1000 mm)
